Die-casting Aluminium body, tempered glass
Color temperature (in Kelvin) available:
2700K, 3000K, 3500K, 4200K, 5000K, 6500K
Color rendering Index(Ra)available ≥ 80
Working Temperature: -20°C~50°C
Detection area: 120° Detection Angle
Max. distance approx: 10±2M
Duration time: 10±5 Sec.to 5±1 Minutes Adjustable Voltage: 230V~ 50/60Hz
IP54, IP65
Model | Power | Total Luminous Flux | Useful Luminous Flux | Peak Intensity |
Dimension(mm) L x B x H |
LN4291S/LN4291S1 | 10W | 1150LM | 950LM | 400cd | 115x37x155.5 |
LN4292S/LN4292S1 | 20W | 2300LM | 1900LM | 800cd | 140x37x173.5 |
LN4293S/LN4293S1 | 30W | 3500LM | 2850LM | 1200cd | 181x37x209.5 |
LN4295S/LN4295S1 | 50W | 5800LM | 4750LM | 2000cd | 232x37x248.5 |
